0.8mm Pitch Twin U Slot Insulation Displacement Connector with 3 Point Grip Construction
0.8mm pitch/disconnectable Insulation displacement IDC connectors ,equivalent of JST 02SUR-32S
The world's first 0.8mm pitch wire-to-board insulation displacement connector.
Although this shrouded header has locking features for its mating receptacle, there are no holes in the header shroud that would adversely effect vacuum gripping equipment.
- 3-point grip construction
- Super fine wires are applicable
- Shrouded header
- Twin U-slot insulation displacement section
Specification Standardized:
Pitch: 0.8mm
Poles: 2-18
Applicable wire: AWG 32
Voltage rating: 30V AC/DC
Current rating: 0.5A AC/DC
Withstand voltage: 200V AC/minute
Working temperature: -40°C to +85°C
Insulation resistance: 5000MΩ Min
Contact resistance: 20MΩ Max.
Material Specification :
Housing :Nylon 66 UL94V-0
Wafer: Thermal Plastic,UL94V-0
PIN: Phosphor Bronze ,Gold plated
Payment Details:
Payment Terms:T/T or Western Union
Minimum Order:1000 Pieces
Primary Competitive Advantages:
- Service
- Country of Origin
- Experienced Staff
- Guarantee/Warranty
- International Approvals
- Price
- Prompt Delivery
- Quality Approvals
|
Main Export Markets:
- Asia
- Australia
- Central/South America
- Mid East/Africa
- North America
|
Equipment and Service:
10 automated infection molding,20 automated pin-setting and 6 high-precision stamping machines
prefessional and patient pre-service & after-service
professsional sales team & engineering team & techinology team
puntual delivery time and complete packaging process
preferable price and best quality
