8 Pole SMD PCB Mount Connectors With 3A AC / DC Rating Current -40°C - +85°C

Product Categories

Dongguan JVT Connectors Co., Ltd

Contact Now

8 Pole SMD PCB Mount Connectors With 3A AC / DC Rating Current -40°C - +85°C

Brand Name : JVT

Model Number : JVT3026WLP-2X02SWRP1-S

Certification : ISO9001/SGS/UL/ROHS/Reach

Place of Origin : China

MOQ : 1000 PCS

Price : Negotiation

Payment Terms : T/T or Western Union

Supply Ability : 300000 per month

Delivery Time : 7-10 working days

Packaging Details : PE bag packing +outer carton

Pitch : 3.0mm

Color : Black

Rating Current : 3A AC/DC

No.of Pins : 8

Product Category : Headers & Wire Housings

Mounting Style : SMD

Contact Now

Micro-Fit 3.0™ Right Angle Header, 3.00mm Pitch, Dual Row, 6 Circuits, with PCB Press-fit Metal Retention Clip, Tin, Glow Wire Compliant, Black

Datasheet (PDF) & Other Documents Download center:

1.JVT3026WLP-2XXSNRP1-S.pdf

2.2016 JVT catalogue.pdf

3. PCB SMT header connector.pdf

8 Pole SMD PCB Mount Connectors With 3A AC / DC Rating Current -40°C - +85°C

Specification Standardized:

Pitch	3.0mm
Poles	8
Applicable wire	28#
Rating Voltage	200V AC/DC
Rating Current	3A AC/DC
Withstand voltage	1000V AC/minute
Operating temperature	-40°C to +85°C
Insulation resistance	1000MΩ Min
Contact resistance	20MΩ Max.

Payment Details:

Payment Terms:T/T or Western Union

Minimum Order:1000 Pieces

JVT offer a complete range of board to board and board to wire connectors including :pin header ,mini jumpers,female header ,PCB Multipole and housing a wide range of applications including :industrial ,Medical and automotive .

All are offered with small moq's ,the majority being stocked items .

Product Tags:

pcb mount connectors

pcb header connectors

8 Pole SMD PCB Mount Connectors With 3A AC / DC Rating Current -40°C - +85°C Images
