JVT 2.0mm Wire Connectors 6 Poles Nylon 66 V-0 Wire To Board Connector Use

Product Categories

Dongguan JVT Connectors Co., Ltd

Contact Now

JVT 2.0mm Wire Connectors 6 Poles Nylon 66 V-0 Wire To Board Connector Use

Brand Name : JVT

Model Number : JVT1148&1149

Certification : ISO9001/SGS/UL/ROHS/Reach

Place of Origin : China

MOQ : 1000 PCS

Price : Negotiation

Payment Terms : T/T or Western Union

Supply Ability : 300000 per month

Delivery Time : 7-10 working days

Packaging Details : PE bag packing +outer carton

Equivalent : Molex 39-020-2020

pitch : 4.2mm

Application : Power, Wire-to-Board, Wire-to-Wire

Gender : Receptacle

Contact Now

JVT 2.0mm male and female housing connector ,6poles ,Nylon 66 V-0 ,wire to baord connector type

Positive locking housings

Easy to operate thumb latch assures connectors are fully mated.

Positive locking prevents accidental unmating.

Available in UL94V-0, V-2, 265°C reflow, Glow-Wire and Low-Halogen compliant materials

Ideal for many applications to meet global material requirements

Specifications :

Part Number: JVT2003HNO-03

Category: wire to board connector ,power connector ,wire to wire connector

Terminal: Brass , Tin-plated

Housing: PA66,UL94V-0

Wafer: Nylon 66 ,Tin plated

Pitch: 2.0mm

Poles:2-16

Applicable wire: AWG#18-22

Voltage rating: 250V AC/DC

Current rating: 5A AC/DC

Withstand voltage: 1500V AC/minute

Working temperature: -40°C to +105°C

Insulation resistance: 1000MΩ Min

Contact resistance: 20MΩ Max.

JVT 2.0mm Wire Connectors 6 Poles Nylon 66 V-0 Wire To Board Connector Use

Payment Details:

Payment Terms:T/T or Western Union

Minimum Order:1000 Pieces

Primary Competitive Advantages:

Service
Country of Origin
Experienced Staff
Guarantee/Warranty
International Approvals
Price
Prompt Delivery
Quality Approvals

Main Export Markets:

Asia
Australia
Central/South America
Mid East/Africa
North America

Equipment and Service:

10 automated infection molding,20 automated pin-setting and 6 high-precision stamping machines

prefessional and patient pre-service & after-service

professsional sales team & engineering team & techinology team

puntual delivery time and complete packaging process

preferable price and best quality
