2 - 20 Poles Mini Jumper Pin Connector with PA66 UL94V-0 Housing Brass PIN Gold Plated

Product Categories

Dongguan JVT Connectors Co., Ltd

Contact Now

2 - 20 Poles Mini Jumper Pin Connector with PA66 UL94V-0 Housing Brass PIN Gold Plated

Brand Name : JVT

Model Number : CX-JVT-2548

Certification : ISO9001/SGS/UL/ROHS/Reach

Place of Origin : China

MOQ : 1000 PCS

Price : Negotiation

Payment Terms : T/T or Western Union

Supply Ability : 300000 per month

Delivery Time : 7-10 working days

Packaging Details : PE bag packing +outer carton

Pitch : 2.54mm

No.of Rows : 14

Rating Current : 200V AC/DC

contact plating : tin plated

contact material : Brass

Color : kinds of

Contact Now

2 Poles Jumper Shorting Pin Connector with PA66 UL94V-0 Housing Brass PIN Gold Plated

2.5mm Cables Mini Jumper Connector for Application of AWG # 28 - 32

Technical Datasheets:

Specification Standardized:

Pitch	2.5mm
Poles	2-20
Applicable wire	#28-32
Rating Voltage	200V AC/DC
Rating Current	3A AC/DC
Withstand voltage	1000V AC/minute
Operating temperature	-40°C to +85°C
Insulation resistance	1000MΩ Min
Contact resistance	20MΩ Max.

Material Specification :

Housing: PA66,UL94V-0

PIN: Brass,Gold plated

Payment Details:

Payment Terms:T/T or Western Union

Minimum Order:1000 Pieces

Primary Competitive Advantages:

Service
Country of Origin
Experienced Staff
Guarantee/Warranty
International Approvals
Price
Prompt Delivery
Quality Approvals

Main Export Markets:

Asia
Australia
Central/South America
Mid East/Africa
North America

Equipment and Service:

10 automated infection molding,20 automated pin-setting and 6 high-precision stamping machines

prefessional and patient pre-service & after-service

professsional sales team & engineering team & techinology team

puntual delivery time and complete packaging process

preferable price and best quality

Product Tags:

jumper pin connector

mini pin connector

2 - 20 Poles Mini Jumper Pin Connector with PA66 UL94V-0 Housing Brass PIN Gold Plated Images
